Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 4-2-5 P/N 73-0018-00 (Revision B)
Outline Sheet 4-2-1
XYZ Axis Failure
A. Introduction
The dispense head moves to the left, right, back and front on the X/Y-Axis rods. The
dispense head moves up and down on the Z-axis rod. Axis failure can be attributed to a
variety of causes.
B. Enabling Objective
4.2 Identify necessary steps to isolate XYZ axis failure and perform appropriate
recovery procedures.
C. Topic Outline
1. Introduction
2. Overview
 Symptoms and Causes of XYZ Axis Failure
3. Summary and Review
