Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 4-2-42 P/N 73-0018-00 (Revision B)
Information Sheet 4-11-1
Fuses
A. Removing and Replacing Fuses
1. The number of fuses on M-2000 Series Dispensing Systems varies depending upon
the system configuration. There are 2 types of fuses:
 Board Mounted Fuses
 Panel Mounted Fuses
2. Make sure that all system power is OFF when replacing fuses or serious bodily
injury and/or damage to the dispensing system will occur.
B. Board-Mounted Fuse
1. These fuses are found in holders on printed wiring boards located inside the
Computer and the Conveyor Controller.
2. This fuse prevents the boards from being damaged in case of overloads.
C. Panel Mounted Fuse
1. These fuses are located on the front panel of the Conveyor Controller.
2. The fuses prevent the controller from being damaged in case of a power surge from
the Board Heaters.
