Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 1-2-16 P/N 73-0018-00 (Revision B)
Information Sheet 1-3-1
Power Supply and AC Distribution
A. Main Power Inlet/Circuit Breaker
1. The Main Power Inlet is the main source of power for the entire machine and is
located on the rear bottom of the machine (See Diagram Sheet 1-3-1 on page
1-2-17).
2. It connects the machine to the facility power source through the main power cord.
3. Switching the Circuit Breaker to the OFF (O) position cuts power to the entire
system.
B. Main Power Cord
1. Connects to the facility main power source outlet, either 110/120V or 220/240V
depending on the system configuration.
2. Systems with IR heaters have a separate power cord that connects directly to the
AC power source.
C. Start Button
1. The Start button is located on the front panel and puts the dispensing system in a
power-on state (See Diagram Sheet 1-3-2 on page 1-2-18).
2. The Start button must be pushed to allow full power to the entire system.
D. Safety Precautions
1. Disconnect all power cords before servicing electrical components.
2. When performing service or maintenance work on the dispensing system in areas
marked with an Electrical Warning Label, it is recommended that you turn the Main
Circuit Breaker OFF and lock it in the OFF position with a padlock.
