Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-49 P/N 73-0018-00 (Revision B)
Diagram Sheet 2-7-1
Height Sensors
LK-Series Laser Height Sensor
Probe
Solenoid
Micromete
r
Locking Scre
w
LED Indicator
Probe Set Screw
Micromete
r
A
djustmen
t
Mounting Bracket
HS-Series Hei
g
ht Senso
r
