Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-83 P/N 73-0018-00 (Revision B)
Diagram Sheet 2-11-1
Contact Heaters
Contact Heater Configuration
Contact
Heaters
Close-up o
f
Individual
Heate
r
Vacuum Hole
Loop 1
Loop
2
Loop 3
Pre-Heat Zone Dispense Heat Zone Post-Heat Zone
