Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-101 P/N 73-0018-00 (Revision B)
Diagram Sheet 2-13-1
Board Sensor Locations
Upward Facing Sensor Location
Downward Facing Sensor Location
Opti
c
Senso
r
Optic Sensor
Front Conveyor
Rail (may vary
depending on
system
configuration)
Sensor
Sensitivity
Adjustments
Optic Sensor
Sensor Sensitivity
Adjustments
Optic
Sensor
Front Conveyor
Rail
(may vary
depending on
system
configuration)
