Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 1-2-6 P/N 73-0018-00 (Revision B)
Information Sheet 1-1-4
Front Cabinet Features
1. Precision Fluid Air Gauges and Regulator
– The Precision Fluid Air Gauge and Regulator
supplies air to the fluid syringe. It receives air from the fluid Air Gauge and Regulator
located in the rear of the dispensing system.
2. Heat Station Timers
– The Heat Station Timers are an option available on systems
equipped with heaters. The timers can be used to keep a part in the pre-heat or post-
heat zones for a specified amount of time.
3. Electronic Scale Display
– The electronic scale is an option available on systems
performing applications that require periodic flow rate calibrations.
4. Computer Controls
– The Computer Control Panel includes the disk drive, CD ROM Drive,
Hard Drive Activity Indicator, Power Indicator, Reset Switch and Power Switch.
