Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 1-2-8 P/N 73-0018-00 (Revision B)
Information Sheet 1-1-5
Equipment Features (Rear)
1. Emergency Machine Off (EMO)
– Allows you to quickly power down the machine in case
of emergency.
2. Main Air Gauge and Regulator
- The Main Air Gauge and Regulator supplies air to all of
the other system gauge and regulator sets.
3. Rear Access Door
– The rear access door allows access to the back of the dispensing
system. The pneumatic valves and solenoids controlled by all of the pressure gauge and
regulator sets are located inside of the rear access door.
4. Main Power Cord
– The Main Power Cord connects the Main Power Inlet on the dispensing
system to the facility power source.
5. Main Circuit Breaker
– The Main Circuit Breaker controls the power supplied through the
Main Power Inlet. Turning the Main Circuit Breaker OFF cuts power to the Power
Manager and therefore to the entire system and all system components.
6. Power Manager
– The Power Manager receives power through the Main Power Inlet and
supplies power to the Power Supply, the system computer, the Conveyor Control
Module(s), the Heater Relay Module, the Temperature Control Module and the Moritex
Light Source, if present.
