Automatic Operation (Synchronous Control)
9-40
Axis
no.
Unit
memory
no. (Hex)
Name Default Unit Setting range and description
- UM 66F47
Reserved for
system
- - -
- UM 66F48
Start phase of
section 2
U0 0.01%
Just like the area for the section 1, set the start
phase, displacement and cam curve.
- UM 66F49
Displacement
of section 2
K0 0.01%
- UM 66F4A
Cam curve of
section 2
U0 -
- UM 66F4B
Reserved for
system
- -
- UM 66F4C
Start phase of
section 3
U0 0.01%
- UM 66F4D
Displacement
of section 3
K0 0.01%
- UM 66F4E
Cam curve of
section 3
U0 -
- UM 66F4F
Reserved for
system
- -
- UM 66F50
Start phase of
section 4
U0 0.01%
- UM 66F51
Displacement
of section 4
K0 0.01%
- UM 66F52
Cam curve of
section 4
U0 -
- UM 66F53
Reserved for
system
- -
- UM 66F54
Start phase of
section 5
U0 0.01%
- UM 66F55
Displacement
of section 5
K0 0.01%
- UM 66F56
Cam curve of
section 5
U0 -
- UM 66F57
Reserved for
system
- -
