9.6 Electronic Cam Function
9-41
Axis
no.
Unit
memory
no. (Hex)
Name Default Unit Setting range and description
- UM 66F58
Start phase of
section 6
U0 0.01%
Just like the area for the section 1, set the start
phase, displacement and cam curve.
- UM 66F59
Displacement
of section 6
K0 0.01%
- UM 66F5A
Cam curve of
section 6
U0 -
- UM 66F5B
Reserved for
system
- -
- UM 66F5C
Start phase of
section 7
U0 0.01%
- UM 66F5D
Displacement
of section 7
K0 0.01%
- UM 66F5E
Cam curve of
section 7
U0 -
- UM 66F5F
Reserved for
system
- -
- UM 66F60
Start phase of
section 8
U0 0.01%
- UM 66F61
Displacement
of section 8
K0 0.01%
- UM 66F62
Cam curve of
section 8
U0 -
- UM 66F63
Reserved for
system
- -
- UM 66F64
Start phase of
section 9
U0 0.01%
- UM 66F65
Displacement
of section 9
K0 0.01%
- UM 66F66
Cam curve of
section 9
U0 -
- UM 66F67
Reserved for
system
- -
