Automatic Operation (Synchronous Control)
9-42
Axis
no.
Unit
memory
no. (Hex)
Name Default Unit Setting range and description
- UM 66F68
Start phase of
section 10
U0 0.01%
Just like the area for the section 1, set the start
phase, displacement and cam curve.
- UM 66F69
Displacement
of section 10
K0 0.01%
- UM 66F6A
Cam curve of
section 10
U0 -
- UM 66F6B
Reserved for
system
- -
- UM 66F6C
Start phase of
section 11
U0 0.01%
- UM 66F6D
Displacement
of section 11
K0 0.01%
- UM 66F6E
Cam curve of
section 11
U0 -
- UM 66F6F
Reserved for
system
- -
- UM 66F70
Start phase of
section 12
U0 0.01%
- UM 66F71
Displacement
of section 12
K0 0.01%
- UM 66F72
Cam curve of
section 12
U0 -
- UM 66F73
Reserved for
system
- -
- UM 66F74
Start phase of
section 13
U0 0.01%
- UM 66F75
Displacement
of section 13
K0 0.01%
- UM 66F76
Cam curve of
section 13
U0 -
- UM 66F77
Reserved for
system
- -
