9.6 Electronic Cam Function
9-43
Axis
no.
Unit
memory
no. (Hex)
Name Default Unit Setting range and description
- UM 66F78
Start phase of
section 14
U0 0.01%
Just like the area for the section 1, set the start
phase, displacement and cam curve.
- UM 66F79
Displacement
of section 14
K0 0.01%
- UM 66F7A
Cam curve of
section 14
U0 -
- UM 66F7B
Reserved for
system
- -
- UM 66F7C
Start phase of
section 15
U0 0.01%
- UM 66F7D
Displacement
of section 15
K0 0.01%
- UM 66F7E
Cam curve of
section 15
U0 -
- UM 66F7F
Reserved for
system
- -
- UM 66F80
Start phase of
section 16
U0 0.01%
- UM 66F81
Displacement
of section 16
K0 0.01%
- UM 66F82
Cam curve of
section 16
U0 -
- UM 66F83
Reserved for
system
- -
- UM 66F84
Start phase of
section 17
U0 0.01%
- UM 66F85
Displacement
of section 17
K0 0.01%
- UM 66F86
Cam curve of
section 17
U0 -
- UM 66F87
Reserved for
system
- -
