16.7 Unit Memories (Each Axis Setting Area)
16-71
●: Available, -: Not available
Buffer no.
Unit
memory
no. (Hex)
Name Default Description R W
1 UM 06246
Extended
positioning
table usage
setting
H0
Set whether to use the extended positioning table
or not.
bit Name Description
15-0
Extended
positioning
table usage
setting
0: Not make the table
setting
1: Make the table setting
Any other settings will be
errors.
* When using the extended positioning table;
table nos. 401 to 500 is used as extended table
nos. 10,001 to 10,100.
 
1 UM 06247
Extended
positioning
table usage
setting
corresponding
axis no.
U0
Set transfer axis numbers of positioning data.
Range
Corresponding axis no.
1 to 64
Corresponds to the existing axes 1 to
64.
65 to 96
Corresponds to the virtual axes 1 to 32.
Any other settings will be errors.
 
