Specifications
16-86
●: Available, -: Not available
Axis no.
Unit
memory
no. (Hex)
Name Default Description R W
- UM 66F44
Start phase
of section 1
U0
When reading, the start phase in the section 1 of
the read cam pattern table is stored. The read value
is always 0.
When rewriting, the start phase in the section 1 of
the rewritten cam pattern table is set. When any
value other than 0 is set in the section 1, it cannot
be rewritten correctly.
bit Name Description
15-0 Start phase
(0 to 100.00%)
Any other settings will be
When reading, stores it truncating the numbers
beyond the third decimal point.
When rewriting, the numbers beyond the third
decimal point are calculated in the unit and the
result is registered.
- UM 66F45
of section 1
K0
When reading, the displacement in the section 1 of
the read cam pattern table is stored.
When rewriting, the displacement in the section 1 of
the rewritten cam pattern table is set.
bit Name Description
15-0
Displacement
（-100.00% to +100.00%）
Any other settings will be
When reading, stores it truncating the numbers
beyond the third decimal point.
When rewriting, the numbers beyond the third
decimal point are calculated in the unit and the
result is registered.
