Parker AC30 series User Manual

Fieldbuses A-53
AC30 series Variable Speed Inverter
Parameter Name
No.
Path
Default
Range
Writable
PROFINET State
3143
Monitor::Communications::Base PROFINET
Parameters::Base Comms::PROFINET IO Device
NONE
0: SETUP
1: NW_INIT
2: WAITING TO
CONNECT
3: STOP MODE
4: CONNECTED
5: ERROR
6, 7: Reserved
8: NONE
NEVER
PROFINET IO parameter.
Diagnostic indicating the state of the PROFINET IO Device.
Enumerated values:
0: SETUP
PROFINET IO enabled – the inverter is in the configuration state
1: NW_INIT
Network initialization
2: WAITING TO CONNECT
Waiting for a connection to a PLC
3: STOP MODE
Connection made in Stop Mode – inverter parameters will not be written to by the PLC
4: CONNECTED
Connection made in Run mode
5: ERROR
Configuration error
8: NONE
PROFINET IO disabled
PROFINET Diagnostic
3144
Monitor::Communications::Base PROFINET
Parameters::Base Comms::PROFINET IO Device
NONE
0: NONE
1: INPUT MAPPING
FAILED
2: OUTPUT MAPPING
FAILED
3: CONNECTION
REJECTED
4: MAPPING MISMATCH
NEVER
PROFINET IO parameter.
Diagnostic indicating if there is a configuration error.
Enumerated Values:
0: NONE
No configuration error
1: INPUT MAPPING FAILED
Invalid input mapping
2: OUTPUT MAPPING FAILED
Invalid output mapping
3: CONNECTION REJECTED
Inverter has rejected a connection attempt from the PLC due to invalid switching
frequency and update time combination.
4: MAPPING MISMATCH
The mapping between the PLC and inverter does not match. A connection may still be
allowed in this state.

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
