C-158 Parameter Reference
AC30 series Variable Speed Drive
Raise Lower
Setup::Application::Raise Lower
Monitor::Application::Raise Lower*
Appears when the Raise/Lower macro is selected.
The Raise/Lower function acts as an internal motorised potentiometer (MOP) used as a reference source.
Parameter Name
No.
Path
Default
Range
Units
Writable
RL Ramp Time
1901
Setup::Application::Raise Lower
10.0 0.0 to 600.0
s
ALWAYS
Rate of change of the Output. Defined as the time to change from 0.00% to 100.00% . Note that the raise and lower rates are always
the same.
L Reset Value
1902
Setup::Application::Raise Lower
0.0 -500.0 to 500.0
%
ALWAYS
The value Output is set to when the Reset Input is TRUE.
RL Maximum Value
1903
Setup::Application::Raise Lower
100.0
-500.0 to 500.0
%
ALWAYS
The maximum value to which Output will ramp up to.
RL Minimum Value
1904
Setup::Application::Raise Lower
-100.0
-500.0 to 500.0
%
ALWAYS
The minimum value to which Output will ramp down to.
Reset Input
This is connected to a Digital Input as part of the selected Macro. When TRUE forces Output to track Reset Value.
Raise Input
This is connected to a Digital Input as part of the selected Macro. When TRUE causes Output to ramp up.
