Parker AC30 series User Manual

Trips & Fault Finding 7-9
AC30 series Variable Speed Inverter
Runtime Alerts
A Runtime Alert is a fault that indicates a permanent hardware error. The Runtime Alert display is of the form
RUNTIME ALERT
CODE 00000000 xx
CODE is a number in the range 0 to 65000. The following value is used to provide additional information to assist Parker Hannifin Technical
Support personnel.
CODE
ERROR
Possible Reason for Error
1 to
255
Internal exception
•
VCM not secured to power stack
• Option not secured correctly to VCM control card
• Earth bonding failure.
•
Fault during firmware upgrade
12
Memory access
•
Attempt to read or write to protected memory. Most likely this will be due to a configuration error. Press
OK several times until the drive resets correctly, then replace the configuration using PDQ.
•
Record the error message and contact Technical Support
1001
to
1003
Processor overload
• Select a lower switching frequency, (Parameters::Motor Control::Pattern Generator::Stack Frequency)
• Record the error message and contact Technical Support
1006
Memory overflow
•
Reduce the complexity of the application
• Reduce the number of parameters being accessed via the on board Modbus TCP protocol
• Reduce the number of parameters being accessed by the fieldbus communications option.
1007
Uninitialized pointer
•
Record the error message and contact Technical Support
1010,
1101
to
1113
Initialization error
• Record the error message and contact Technical Support
1200
to
1299
Communications option
error
•
Ensure the communications option is correctly fitted
• Update the firmware in the inverter.
•
Replace the communications option
1300
Ethernet fault
•
Record the error message and contact Technical Support

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
