Parker AC30 series User Manual

Menu Organisation 5-1
AC30 series Variable Speed Inverter
Chapter 5: Menu Organisation
Menu Map
The Menu System consists of a series of menus and sub-menus organised into a “tree” structure. Navigate around the tree on the GKP using the
UP, DOWN, LEFT and RIGHT keys. Individual parameters may be present in the menu tree at more than one location. Parameters and/or
menus that are not required or are empty are automatically hidden on the GKP and web page.
Menu Map Summary
Control Screen
Clone
Setup
Environment
Quick Setup
Monitor
Application
Quick Monitor
Motor Control
Application
Control & Type
Motor & Drive
Motor Nameplate
Inputs and Outputs
Motor Data PMAC
System Board
Auto Restart
Encoder Slot 1
Autotune
Encoder Slot 2
SVC PMAC
Communications
Pos Fbk Alignment
Base Ethernet
Regen Control
Base Modbus
Inputs and Outputs
Base Ethernet IP
Base IO
Option
Option
PTP
System Board Option
Peer to Peer
SB Encoder Slot1
Energy Meter
SB Encoder Slot2
Trips
Communications
Regen Control
Base Ethernet
Favourites
Base Modbus
Parameters*
Base Ethernet IP
Option
PTP
Peer to Peer
* The “Parameters” menu is intended for expert use only, see Appendix D

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
