Parker AC30 series User Manual

C-90 Parameter Reference
AC30 series Variable Speed Drive
Induction Motor Data
Setup::Motor Control::Induction Motor Data
Parameters::Motor Control::Induction Motor Data
Only available if IM MOTOR selected in Control Mode
Parameter Name
No.
Path
Default
Range
Units
Writable
Magnetising Current
0568
Parameters::Motor Control::Induction
Motor Data
1.00 0.00 to 10000.00 A
ALWAYS
The no load current of the induction motor, defined as rotor flux / magnetising inductance, usually given the title "imr".
Rotor Time Constant
0569
Parameters::Motor Control::Induction
Motor Data
0.100 0.005 to 100.000 s
ALWAYS
Induction Motor rotor time constant.
Leakage Inductance
0570
Parameters::Motor Control::Induction
Motor Data
1.000 0.000 to 1000.000 mH
ALWAYS
Induction motor leakage inductance. Displayed as star or delta equivalent value according to "Per Phase Parameters" setting.
Stator Resistance
0571
Parameters::Motor Control::Induction
Motor Data
0.0000 0.0000 to 100.0000 Ohm
ALWAYS
Induction motor stator resistance. Displayed as star or delta equivalent value according to "Per Phase Parameters" setting.
Stator Resistance
0571
Parameters::Motor Control::Induction
Motor Data
0.0000 0.0000 to 100.0000 Ohm
ALWAYS
Induction motor rotor resistance. Displayed as an interim “by-product” of stationary autotune procedure. Not used in control functions.
Mutual Inductance
0572
Parameters::Motor Control::Induction
Motor Data
100.00 0.00 to 10000.00 mH
ALWAYS
Induction motor mutual inductance. Displayed as star or delta equivalent value according to "Per Phase Parameters" setting.
