Parker AC30 series User Manual

The Graphical Keypad 4-9
AC30 series Variable Speed Inverter
Setup Wizard
The purpose of the Setup Wizard is to configure the inverter in a clear and concise manner.
Starting the Setup Wizard
The Setup Wizard is automatically invoked when the inverter is reset to factory default settings.
Alternatively, the Setup Wizard may be invoked at any other time by navigating to the ‘Welcome Screen’ at the top of the menu tree and pressing
Soft Key 1, as shown by the Setup Wizard indicator.
Note: It is always recommended that the Setup Wizard is completed once started.
Navigating the Setup Wizard
At each step of the Setup Wizard, pressing the OK key selects the displayed value and also moves on to the next step.
Pressing Soft Key 1 moves back a step.
Pressing the UP and DOWN keys modifies the parameter value.
Note: Accepting each choice without change by pressing OK will result in no change to the inverter’s configuration.
Setup Wizard Stages
The Setup Wizard starts by asking what user view level is required for the GKP, followed by a list of languages for which the user selects their
preference.
The user will then be asked if they would like to continue and run the Wizard. If ‘yes’, the first option is to “Set Factory Defaults”. Changing this
parameter to TRUE then pressing OK resets all parameters back to the default value determined by the inverters hardware configuration. In most
case, this is recommended. If this choice is left FALSE the setup wizard starts with all parameters with their previously set values.
The rest of the Setup Wizard consists of several sections, each of which corresponds to a functional component of the inverter, for example:
- Application selection
- IO Option, (includes the Encoder)
- Analog input and output ranges.
- Motor Data
- Motor Control
- Fieldbus options
- On-board Ethernet
- Auto tune
If not required, any section may be skipped.
The default setting for all parameters depends on earlier answers and on the physical configuration of the inverter. All data entered is
automatically saved without the need for any additional commands.
Finalising Setup
Once the Setup Wizard has been run to completion, the feature is automatically disabled. Power cycling to the inverter will not cause the Setup
Wizard to be run again, though If this is required, this can be achieved as detailed above in ‘Starting the Setup Wizard’.
Refer to chapter 6 for a more detailed explanation of the Setup Wizard

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
