Parker AC30 series User Manual

Product Overview 3-7
AC30 series Variable Speed Inverter
AC30 Series Control Features
The inverter is fully featured when controlled using the optional Keypad (or a suitable pc programming tool).
General
Motor Control Modes
Induction motor:
- V/F control
- Sensorless Vector Control
- Closed Loop Vector Control (with encoder option)
- Closed Loop Vector Control (with resolver option)
PMAC motor:
- Sensorless Vector Control
- Closed Loop Vector Control (with encoder option)
- Closed Loop Vector Control (with resolver option), though with power constraints
AFE Mode
4Q Regen Control (with encoder option)
Voltage Boost for V/F control
0-25%
Skip Frequencies
Skip frequencies with adjustable skip band width
Preset Speeds
User selectable preset speeds
Stopping Modes
Ramp, Coast, DC Injection, Quickstop
S Ramp and Linear Ramp
Symmetric or asymmetric ramp up and down rates
Raise/Lower
Programmable MOP function
Jog
Programmable jog speed
Diagnostics
Full diagnostic and monitoring facilities
Inputs/
Outputs
Analog Inputs
2 configurable inputs: 1 voltage or current, 1 voltage only
Analog Outputs
2 configurable outputs: 1 unipolar voltage or current, 1 bipolar voltage only
Digital Inputs
3 configurable 24V dc inputs
System Board Digital Inputs
3 configurable 24V dc inputs (AC30D & AC30A only)
Digital I/O
4 configurable 24V dc current sourcing outputs/digital inputs
System Board Digital I/O
3 configurable 24V dc current sourcing outputs/digital inputs (AC30A only)
Relay Outputs
2 configurable relay outputs (AC30V only)
Reference Voltages
+/-10V dc outputs, user +24V dc output
Aux Supply
+24V dc input
Encoder Inputs
2 separate encoder input channels: A, /A, B, /B, Z, /Z (AC30D only)
1 sin/cos encoder input channel: sin+, sin-, cos+, cos-, Z, /Z & 1 Endat 2.1 encoder input
channel: Data+, Data-, Clock+, Clock- (AC30A only)
Encoder Supply Outputs
1 selectable encoder output supply voltage (AC30D & AC30A only)
Encoder Outputs
1 encoder transmit channel: A, /A, B, /B, Z, /Z (AC30D & AC30A only)
Comms
On-board Ethernet
1 port (AC30V only)
2 ports

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
