6-3 Setup Wizard
AC30 series Variable Speed Inverter
Application selection
Selection of the specific Macro and associated parameters.
PNO
Parameter
Validity
Comment
Setup Application?
Select YES to configure the application parameters, NO to skip this section
1900
Selected Application
BASIC SPEED
CONTROL
AUTO/MANUAL
CONTROL
SPEED
RAISE/LOWER
SPEED
PRESETS
PROCESS PID
AFE
1937
Disable Coast Stop
1938
Disable Quickstop
1901
RL Ramp Time
Sets the rate of change of the output of the Raise/Lower ramp.
1902
RL Reset Value
The value of the Raise/Lower ramp output when reset.
1903
RL Maximum Value
The upper limit of the Raise/Lower ramp output.
1904
RL Minimum Value
The lower limit of the Raise/Lower ramp output
1916
Preset Speed 0
The preset speed output when the selected preset is 0.
1917
Preset Speed 1
The preset speed output when the selected preset is 1.
1918
Preset Speed 2
The preset speed output when the selected preset is 2.
1919
Preset Speed 3
The preset speed output when the selected preset is 3.
1920
Preset Speed 4
The preset speed output when the selected preset is 4.
1921
Preset Speed 5
The preset speed output when the selected preset is 5.
1922
Preset Speed 6
The preset speed output when the selected preset is 6.
1923
Preset Speed 7
The preset speed output when the selected preset is 7.
1926
PID Setpoint Negate
Changes the sign of the setpoint input.
1927
PID Feedback
Negate
Changes the sign of the feedback input.
1928
PID Prop Gain
The proportional gain of the PID controller.
1929
PID Integral TC
The integral time constant of the PID controller.
1930
PID Derivative TC
The derivative time constant of the PID controller.
1931
PID Output Filter TC
The time constant of the first order filter used to filter the PID output.
1932
PID Output Pos Limit
The maximum positive excursion, (limit), of the PID controller.
1933
PID Output Neg Limit
The maximum negative excursion, (limit), of the PID controller.
1934
PID Output Scaling
The overall scaling factor which is applied after the positive and negative limit
clamps
