Parker AC30 series User Manual

Parameter Reference C-85
AC30 series Variable Speed Drive
General Purpose IO
Monitor::Inputs and Outputs
Parameters::Option IO::General Purpose IO
The General Purpose IO parameters configure the use of the four IO Options. This group of parameters is only visible when an IO Option is selected.
Parameter Name
No.
Path
Default
Range
Units
Writable
Anin 11 Value
1181
Monitor::Inputs and Outputs
Parameters::Option IO::General Purpose
IO
x.xx -100.00 to 100.00 %
NEVER
(Terminal X21.2) - The input value expressed as a percentage of range, (+/- 100%), following Offset and Scale.
Anin 12 Value
1182
Same as PNO 1181
x.xx -100.00 to 100.00 %
NEVER
(Terminal X21.3) - The input value expressed as a percentage of range, (+/- 100%), following Offset and Scale.
Anin 13 Value
1183
Same as PNO 1181
x.xx -100.00 to 100.00 %
NEVER
(Terminal X21.4) - The input value expressed as a percentage of range, (+/- 100%), following Offset and Scale.
Anin 11 Offset
1461
Setup::Inputs and Outputs::Option
Parameters::Option IO::General Purpose
IO
0.00 Min to Max %
ALWAYS
The offset is expressed as a percentage of the hardware range. For example an offset of 10% is equivalent to 1V on the input.
The offset is added to the measured value.
Anin 11 Scale
1462
Same as PNO 1461
1.0000 Min to Max
ALWAYS
The scale is a simple multiplication factor. The input voltage is converted to a percentage value. 1461 Anin 11 Offset is added and the
result is multiplied by Scale. The result is presented in parameter 1181 Anin 11 Value.
Anin 12 Offset
1463
Same as PNO 1461
0.00 Min to Max %
ALWAYS
The offset is expressed as a percentage of the hardware range. For example an offset of 10% is equivalent to 1V on the input.
The offset is added to the measured value.
Anin 12 Scale
1464
Same as PNO 1461
1.0000 Min to Max
ALWAYS
