Parker AC30 series User Manual

A-30 Fieldbuses
AC30 series Variable Speed Inverter
Parameter Summary
The following parameters are relevant to the EtherNet/IP adapter.
Parameter Name
No.
Path
Default
Range
Writable
EtherNet IP
Enable
3128
Setup::Communications::Base EtherNet
IP Parameters::Base Comms::EtherNet
IP Adapter
FALSE
FALSE
TRUE
CONFIG
EtherNet/IP adapter parameter. / Enables the built-in EtherNet/IP adapter.
EtherNet IP Trip
3129
Setup::Communications::Base EtherNet
IP Parameters::Base Comms::EtherNet
IP Adapter
LOSS OF
CONNECTION
0: DISABLED
1: LOSS OF
CONNECTION
CONFIG
EtherNet/IP adapter parameter. / Enables the EtherNet/IP trip on loss of connection.
Enumerated values:
0: DISABLED
the trip is disabled
1: LOSS OF CONNECTION
the inverter will trip on the loss of all Class 1 connections
EtherNet IP
State
3130
Monitor::Communications::Base
EtherNet IP
Parameters::Base Comms::EtherNet IP
Adapter
SETUP
0: SETUP
1: NW_INIT
2: WAITING TO
CONNECT
3: CONNECTION IDLE
4: CONNECTION
ACTIVE
5: ERROR
6, 7: Reserved
8: NONE
NEVER
EtherNet/IP adapter parameter.
Diagnostic indicating the state of the EtherNet/IP adapter.
Enumerated values:
0: SETUP
EtherNet/IP adapter enabled – the inverter is in the configuration state
1: NW_INIT
network initialization
2: WAITING TO CONNECT
waiting for a Class 1 connection
3: CONNECTION IDLE
Class 1 connection made with scanner in Idle mode
4: CONNECTION ACTIVE
Class 1 connection made with scanner in Run mode
5: ERROR
configuration error
8: NONE
EtherNet/IP adapter disabled
