Parker AC30 series User Manual

C-30 Parameter Reference
AC30 series Variable Speed Drive
Clone
Setup::Clone
Parameters::Device Manager::Clone
The clone feature allows the drive configuration (application and parameters) to be saved to an SD card and subsequently loaded to the same or a
different drive.
All parameters fall into one of the following cloning categories listed in the parameter table at the end of this appendix:
• Never: This type of parameter would never be copied to a new drive. This category includes parameters that are not saved
and parameters that contain information such as runtime statistics.
• Drive Unique: This type of parameter is normally unique to the drive, such as the drive name.
• Power: This type of parameter is related to the power stack of the drive or to the motor connected to the drive.
• Other: Any saved parameter that is not in the other cloning categories. This category is the majority of the parameters
including the application parameters.
The visibility of the following cloning parameters on the GKP may depend on the selection of other cloning parameters and whether an SD card is
fitted.
Parameter Name
No.
Path
Default
Range
Units
Writable
Clone Filename
1534
Setup::Clone
Parameters
::Device Manager::Clone
clone
ALWAYS
The filename used for saving or loading the clone file. The file extension for clone files is “.cln” and will be added to the filename if it is
not provided by the user.
A single file contains the information for the parameters and the application.
Clone Direction
1537
Same as PNO 1534
0 0:SAVE TO FILE
1:LOAD FROM FILE
ALWAYS
Sets whether a clone save or a clone load should be performed.

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
