8-2 Ethernet
AC30 series Variable Speed Inverters
AC30P or AC30D
Insert the Ethernet cable on an AC30P or AC30D as shown below.
Port 1 LEDs
Activity
Link
Port 2 LEDs
Activity
Link
DO NOT TOUCH
DO NOT touch the board surface via the aperture shown
