Parker AC30 series User Manual

C-94 Parameter Reference
AC30 series Variable Speed Drive
IO Configure
Setup::Inputs and Outputs
Parameters::Inputs And Outputs::IO Configure
These parameters are used to configure the input signal processing.
Parameter Name
No.
Path
Default
Range
Units
Writable
Anin 01 Type
0001
Setup::Inputs and Outputs::Base IO
Parameters::Inputs And Outputs::IO
Configure
0 0:-10..10 V
1:0..10 V
2:0..20 mA
3:4..20 mA
ALWAYS
Analog input 1 is associated with terminal X11.1
The signal processing electronics for analog input 1 supports four input ranges.
Anin 01 Offset
0957
Setup::Inputs and Outputs::Base IO
Parameters::Inputs And Outputs::IO
Configure
0.00 Min to Max %
ALWAYS
The offset is expressed as a percentage of the hardware range selected by 0001 Anin 01 Type. For example, with the 4..20mA range
an offset of 10% is equivalent to 1.6mA on the input.
The offset is added to the measured value.
Anin 01 Scale
0958
Same as PNO 957
1.0000 Min to Max
ALWAYS
The scale is a simple multiplication factor. The input voltage or current is converted to a percentage value. 0957 Anin 01 Offset is
added and the result is multiplied by 0958 Anin 01 Scale. The result is presented in parameter 0039 Anin 01 Value.
Anin 02 Type
0002
Same as PNO 1
0 0:-10..10 V
1:0..10 V
ALWAYS
Analog input 2 is associated with terminal X11.2
The signal processing electronics for analog input 2 supports two input ranges.
