Parker AC30 series User Manual

Parameter Reference C-95
AC30 series Variable Speed Drive
Parameter Name
No.
Path
Default
Range
Units
Writable
Anin 02 Offset
0959
Same as PNO 957
0.00 Min to Max %
ALWAYS
The offset is expressed as a percentage of the hardware range selected by 0002 Anin 02 Type. For example, with the -10..10V range
an offset of 10% is equivalent to 1v on the input.
The offset is added to the measured value.
Anin 02 Scale
0960
Same as PNO 957
1.0000 Min to Max
ALWAYS
The scale is a simple multiplication factor. The input voltage is converted to a percentage value. 0959 Anin 02 Offset is added and the
result is multiplied by 0960 Anin 02 Scale. The result is presented in parameter 0041 Anin 02 Value.
Anout 01 Type
0003
Same as PNO 1
0 0:-10..10 V
1:
0..10 V
4:TORQUE OUT -10..10 V
ALWAYS
Analog output 1 is associated with terminal X11.3
The signal processing electronics for analog output 1 supports two output ranges:
0. -10..10V
1. 0..10V
4. TORQUE OUT : output of the speed loop ( torque setpoint) directly feeding the analog output 1. No delay.
Anout 01 Scale
0686
Setup::Inputs and Outputs::Base IO
Parameters::Inputs And Outputs::IO
Configure
1.0000 Min to Max
ALWAYS
The scale is a simple multiplication factor applied to 0042 Anout 01 Value.
Anout 01 Offset
1108
Setup::Inputs and Outputs::Base IO
Parameters::Inputs And Outputs::IO
Configure
0.00 Min to Max %
ALWAYS
The offset is expressed as a percentage of the hardware range selected by 0003 Anout 01 Type. For example, with the -10..10V
range an offset of 10% is equivalent to 1v on the output.

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
