6-8 Setup Wizard
AC30 series Variable Speed Inverter
On-board Ethernet
Configuration of the on board Ethernet.
PNO
Parameter
Comment
Setup Base Ethernet?
Select TRUE to configure the on board Ethernet port. Select FALSE to skip this section
0929
DHCP
0930
Auto IP
0933
User IP Address
Only visible if DHCP and Auto IP are both FALSE.
0934
User Subnet Mask
Only visible if DHCP and Auto IP are both FALSE.
0935
User Gateway Address
Only visible if DHCP and Auto IP are both FALSE.
Setup Base Modbus?
Select TRUE to configure the on board Ethernet port to also act as a Modbus IP client. Select FALSE to skip the
following parameters
0939
Maximum Connections
Sets the maximum number of Modbus clients allowed. If set to zero, then no connections will be allowed.
0942
Modbus Trip Enable
Set TRUE to enable the Modbus Trip. The parameter Modbus Timeout must be set to a value other than zero
0940
High Word First
If set to TRUE, the most significant word of a 32-bit parameter will be mapped to the first register, and the least
significant word to the next register.
0941
Modbus Timeout
Sets the process active timeout
Setup Base Ethernet IP?
3128
EtherNet IP Enable
Enables EtherNet/IP
3129
EtherNet IP Trip
Trip method for the built-in EtherNet/IP
Setup Base PROFINET?
3132
PROFINET Enable
Enables the built-in PROFINET IO
3133
PROFINET Trip
Enables the trip for the built-in PROFINET IO
Autotune Parameters
Autotune enable and autotune mode. To run the autotune process, complete the wizard then run the inverter.
PNO
Parameter
Comment
0255
Autotune Enable
Select TRUE to enable a motor autotune next time the motor is started. (Only visible for induction motor
sensorless and feedback vector control mode). Refer to Appendix C Parameter Reference for more details.
Finalising Setup
Once the Setup Wizard has been run to completion the feature is automatically disabled. Re-starting the inverter will not cause the Setup Wizard
to be run again. (If it is desired to re-run the Setup Wizard, this can be achieved as detailed above in “Starting the Setup Wizard”).
