6-2 Setup Wizard
AC30 series Variable Speed Inverter
Setup Wizard Stages
The Setup Wizard is divided into sections. With the exception of the first group of parameters, each section may be skipped. The first group of
parameters sets the inverter operating environment.
Select the view level, Operator, Technician or Engineer.
Select the required language to be used on the GKP. There may be a slight pause while the inverter adopts the
selected language.
Select YES to update the inverter’s firmware. Only visible in Engineering view mode with a firmware file on the
SD Card.
Select YES to continue. Select NO to exit with the new settings for View Level and Language
Changing this parameter to TRUE then pressing OK resets all parameters back to the default value determined
by the inverters hardware configuration. If this choice is left FALSE all parameters retain their previously set
Only shown if the control module is not attached to a matching power stack.
Only shown if an IO option with RTC hardware is fitted.
Set to FULL to allow access to parameter values via the web page.
Set to TRUE to automatically save parameter values as they are entered on the GKP and Web page. Set to
FALSE to enable the manual save feature.
All parameters are saved on completion of the GKP wizard regardless of the setting of this parameter. Also, this
parameter is always saved when changed.
Defaults to show the Ethernet MAC address
