Introduction 2-1
AC30 series Variable Speed Inverter
Chapter 2: Introduction
About this Manual
Who is this Manual aimed at?
This Manual is intended for use by the user and programmer of the AC30 series inverters. It assumes a reasonable level of understanding in
these two disciplines.
There are separate hardware installation references - HA503711U001 ‘AC30 Series Hardware Installation Manual: Frames D - J’ and
HA503711U002 ‘AC30 Series Hardware Installation Manual: Frames K - N’ that are intended for use by the installer of the AC30 series inverters.
Note: It is important to always pass on this Manual to any new user of the AC30 series inverter.
How the Manual is Organised?
This Software Reference Manual is organised into chapters, indicated by the numbering on the edge of each page. If the manual is to be printed
it is designed so that it should be printed double-sided using the short-edge for binding.
Information for the operation and programming of the AC30V, AC30P, AC30D & AC30A control modules is detailed in this Manual.
The control module must be mounted on any one of the Frame D, E, F, G, H, J, K, L, M & N power stacks for intended operation. These two
components – control module and power stack, are collectively referred to as “the Inverter” or “drive” throughout the manual.
Product coding: Any “x” within a product code indicates there are variants, see the ‘Appendix D: AC30 Series Product Codes’ section for more
information.
Any text placed in a highlighted area as this sample shows, only refers to the AC30P, AC30D and AC30A control modules.
Parker Hannifin Manufacturing Limited is referred to as “Parker” throughout the manual.
Please read all Safety information before proceeding with the operation of this unit.
