Parker AC30 series User Manual

D-4 AC30 Series Product Codes
AC30 series Variable Speed Drive
AC30 SERIES REGENERATIVE SUPPLY UNIT
Typical example: 380-5R0094-NE-0000 (as shown in the “Order example” above).
This shows the product is an AC30 series regenerative supply unit, rated at 400-500 volts supply, 94A output current rating – 60kW @ 500V,
without a brake switch fitted, Category C3 compliant and no special options.
1 2 4 5 6
380
- 5 R 0094 - N E - 0000
1 4
380 AC30 series regenerative supply unit
N
Without brake s witch ( s ta nda rd)
2
5
5 400 V - 500 V nominal
E
CategoryC3compliant(standard)
3
6
0000 No special options
R0094
94 A / 60 kW
R0157
157 A / 100 kW
S0251
251 A / 160 kW
S0394
394 A / 250 kW
S0536
536 A / 340 kW
Output drive current rating / Nominal driving power @ 500V
Device Family
Voltage
Brake Switch
EMC Filter
Special Options
Frame Size and Current Rating
3
Order example

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
