Parker AC30 series User Manual

6-6 Setup Wizard
AC30 series Variable Speed Inverter
PNO Parameter
Validity
Comment
IM
VHz
IM
VECT
PMAC AFE
0479
PMAC SVC Start Speed
●
The speed setpoint at which the speed control is switched from an
open loop mode to a closed loop mode during the startup procedure
0464
100% Speed in RPM
●
●
●
This is the speed in rpm at which the motor will turn when given a
speed demand of 100%.
0486
Acceleration Time
●
●
●
The time that the inverter will take to ramp the setpoint from 0.00% to
100.00% when Ramp Type is LINEAR.
0487
Deceleration Time
●
●
●
The time that the inverter will take to ramp the setpoint from 100.00%
to 0.00% when Ramp Type is LINEAR.
1257
Seq Stop Method VHz
●
Selects stopping mode that the controller will use once the run
command has been removed when in Volts/Hertz control mode,
0484
Seq Stop Method SVC
●
Selects stopping mode that the controller will use once the run
command has been removed when in Sensorless Vector or Closed
Loop Vector control mode.
0422
VHz Shape
●
Selects the Volts to Frequency curve.
0390
Duty Selection
●
●
●
Selects the inverter rating. Affects the ratio of nominal current
compared with maximum overload current.
1730
AFE Inductance
●
Total inductance (3% + 5%) in the AFE configuration.
1711
AFE VDC Demand
●
DC Link level demand in voltage control mode.
1693
AFE Current Control
●
Sets AFE in current control mode.
1705
AFE Iq Demand
●
Reactive power current demand.
1704
AFE Id Demand
●
Active power current demand.
Fieldbus Options
This section is only shown if a communications option is fitted.
PNO
Parameter
Comment
0044
Comms Required
This defaults to match the communications option that is fitted. If no option is required select NONE. Selecting
a different option will result in a configuration error.
These parameters are shown when the CANopen option is fitted.
PNO
Parameter
Comment
0044
Comms Required
CANOPEN
Refer to CANopen Technical Manual HA501841U001
0212
CANopen Node Address
●
0213
CANopen Baud Rate
●
0048
Comms Trip Enable
●
These parameters are shown when the DeviceNet option is fitted.
PNO
Parameter
Comment
0044
Comms Required
DEVICENET
Refer to DeviceNet Technical Manual HA501840U001

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
