Parker AC30 series User Manual

Fieldbuses A-29
AC30 series Variable Speed Inverter
Ethernet Link Object – F6h
Instance
Attribute
Description
Type
Value
Access
1
2
1
Interface Speed
UDINT
10 or 100
Get
2
Interface Flags
DWORD
Link status
Get
3
Physical address
USINT[6]
MAC address
Get
10
Interface label
SHORT STRING
“Port 1” or “Port 2”
Get
11
Interface capability
Structure of:
Capability bits
Speed/duplex array
count
DWORD
USINT
Auto-negotiation and MDIX supported (6)
0
Get
Supported Service Code
Service Name
01h
Get_Attribute_All
0Eh
Get_Attribute_Single
Vendor Specific Object – 64h
The vendor specific object allows explicit access to AC30 parameters, including string parameters but excluding string arrays.
Instance
Attribute
Description
Type
Access
PNO
1
Parameter Name
SHORT STRING
Get
2
CIP data type
1
USINT
Get
3
Number of parameter
elements
2
USINT
Get
4
Parameter qualifier
Bit 0: Gettable
Bit 1: Settable
BYTE
Get
5
Parameter value
Depends on parameter
Get/Set
6
Parameter min value
Depends on parameter
Get
7
Parameter max value
Depends on parameter
Get
Supported Service Code
Service Name
01h
Get_Attribute_All
0Eh
Get_Attribute_Single
1. Equivalent CIP data types – Volume 1 CIP Specification, Chapter 5A 14.2.1.2
2. For a standard parameter the number of elements will be 1, for a parameter array it will be the number elements in the array, and for a string parameter it will be the maximum
number of characters.
