Parker AC30 series User Manual

7-10 Trips & Fault Finding
AC30 series Variable Speed Inverter
CODE
ERROR
Possible Reason for Error
1301
Modbus server
•
Record the error message and contact Technical Support
1302
HTTP server fault
•
Record the error message and contact Technical Support
1303
DCT server fault
•
Record the error message and contact Technical Support
1311
Ethernet PHY
•
Record the error message and contact Technical Support
1312
Precision Time
Protocol
• Record the error message and contact Technical Support
1313
EtherNet IP
•
Record the error message and contact Technical Support
1314
PROFINET
•
Record the error message and contact Technical Support
1401
1402
Control Module test
• Control module self-test error
1403
1404
Power stack test
•
VCM not secured to power stack
•
Power stack self-test error
1501
1502
1503
IO Option identity
IO Option processor
Unknown IO Option
•
Ensure the IO option is correctly fitted
• Update the firmware in the inverter.
•
Replace the IO option
1504
IO Option watchdog
•
The IO Option has become disconnected
•
Option reset problem. Upgrade drive firmware to 1.11 or greater to improve the option reset control.
1601
Stack internal fault
•
Return the power stack to Parker Hannifin repair center.
1602
Incompatible stack
•
Return the power stack to Parker Hannifin repair center.
1801
Heatsink thermsistor
unplugged
• Return the power stack to Parker Hannifin repair center.
1901
System Board Data
•
The identifying data on the system board is corrupt
1902
System Board Type
•
The system board type is not recognized by this version of drive firmware. Update the firmware to the
latest version.
2001
Unimplemented Function
•
Record the error message and contact Technical Support
2002
Memory allocation error
•
Record the error message and contact Technical Support

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
