Parker AC30 series User Manual

Trips & Fault Finding 7-3
AC30 series Variable Speed Inverter
ID
Trip Name
Possible Reason for Trip
Criteria for Warning
7
MOTOR STALL
The motor has stalled (not rotating) Drive in current limit >200 seconds:
• Motor loading too great
•
FIXED BOOST level set too high
The stall condition has been
detected for more than half of
the configured Stall Time.
8
INVERSE TIME
A prolonged overload condition, exceeding the Inverse Time allowance, has caused the
trip:
•
Remove the overload condition
An overload condition has
exceeded one half of the Inverse
Time allowance.
9
MOTOR I2T
Only for PMAC Motor: A prolonged load condition, exceeding the motor rated
current, has caused the trip. The estimated motor load has reached a value of 105%
An overload condition has
exceeded one half of the motor
Inverse Time allowance.
10
LOW SPEED I
The motor is drawing too much current (>100%) at zero output frequency:
•
FIXED BOOST level set too high
Not applicable.
11
HEATSINK
OVERTEMP
Drive heatsink temperature too high
• The ambient air temperature is too high
• Poor ventilation or spacing between drives
•
Check heatsink fan is rotating
The drive heatsink has exceeded
the warning temperature level
(which is approx. 10
° C below the
trip temperature).
12
INTERNAL
OVERTEMP
Processor temperature or ambient temperature within the power stage too high
• The ambient temperature in the drive is too high
The drive processor temperature
has exceeded the warning
temperature level (which is
approx. 10
° C below the trip
temperature).
13
MOTOR
OVERTEMP
The motor temperature is too high, (required IO Option card)
• Excessive load
• Motor voltage rating incorrect
• FIXED BOOST level set too high
• Prolonged operation of the motor at low speed without forced cooling
•
Break in motor thermistor connection
The motor has been over
temperature for 7.5 seconds.
14
EXTERNAL TRIP
The external (application) trip input is high:
•
Refer to the application description to identify the source of the signal
Not applicable.
15
BRAKE SHORT
CCT
External dynamic brake resistor has been overloaded:
• The external dynamic brake has developed a short circuit.
•
Wiring fault
Not applicable.

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
