General instrument setup

R&S

ZNL/ZNLE

130User Manual 1178.5966.02 ─ 20

IVI Shared Components EULA: Open

Displays a PDF file containing copyright information on the IVI shared components

used by the R&S ZNL/ZNLE firmware.

Install Option

Opens an edit dialog box to enter the license key for the option that you want to install.

Install Option by XML

Opens a file selection dialog box to install an additional option to the R&S ZNL/ZNLE

using an XML file. Enter or browse for the name of an XML file that contains the option

key and select "Select".

7.4.3 System messages

Access: [Setup] > "System Configuration" > "System Messages"

The system messages generated by the R&S ZNL/ZNLE are displayed.

The messages are displayed in the order of their occurrence; the most recent mes-

sages are placed at the top of the list. Messages that have occurred since you last vis-

ited the system messages tab are marked with an asterisk '*'.

If the number of error messages exceeds the capacity of the error buffer, "Message

Buffer Overflow" is displayed. To clear the message buffer use the "Clear All Mes-

sages" button.

The following information is available:

No device-specific error code

Message brief description of the message
