R&S ZNL Series User Manual

VNA GUI reference
R&S
®
ZNL/ZNLE
319User Manual 1178.5966.02 ─ 20
Remote command:
DISPlay[:WINDow<Wnd>]:TRACe<WndTr>:Y[:SCALe]:TOP
DISPlay[:WINDow<Wnd>]:TRACe<WndTr>:Y[:SCALe]:BOTTom
Continuous Auto Scale Trace
Similar to Auto Scale Trace, but applies auto-scaling continuously, even during a run-
ning sweep.
Remote command:
n.a.
10.3.2 Scale Coupling tab
Selects common scale settings for all traces. The softkeys are available if the active
channel setup contains at least two traces, and if the active trace is not a reference
trace ("To Trace").
Related settings
Refer to Chapter 10.6.1.2, "Trace Manager dialog", on page 349.
The "Trace Manager..." button opens the Trace Manager dialog.
Couple All Traces / Couple Trc ... To Trace
Applies the scale settings of the reference trace ("To Trace") to all traces / to the active
trace.
Remote command:
n/a
Scale softtool
