R&S ZNL Series User Manual

VNA concepts and features
R&S
®
ZNL/ZNLE
293User Manual 1178.5966.02 ─ 20
5. Single ended port embedding
9.7 Optional extensions and accessories
The instrument can be upgraded with various hardware and software options, provid-
ing enhanced flexibility and an extended measurement functionality. The equipped
options are listed in the "System Configuration" dialog ([Setup] > "System Config").
Table 9-13: Software options (K-options)
Option Option name
R&S ZNL-K2 Time domain analysis
R&S ZNL-K3 Distance-to-fault measurements
Table 9-14: Hardware options (B-options)
Option Option name
R&S ZNLxx-B1 Spectrum analyzer function
R&S ZN-B13 Broadband limiter
R&S ZNL-B19 Additional removable PC board with SSD
R&S ZNLxx-B22 Extended power range
R&S ZNLx-B31/-B32 Receiver step attenuators
R&S ZNLE-B100 Lower start frequency for R&S ZNLE
Table 9-15: Hardware options (FPL-options)
R&S FPL1-B4 OCXO frequency reference
R&S FPL1-B10 GPIB interface
R&S FPL1-B30 DC power supply 12/24 V
Optional extensions and accessories
