Getting Started
R&S
®
ZNL/ZNLE
71User Manual 1178.5966.02 ─ 20
Figure 4-16: "MultiView" tab with active Sequencer
In Figure 4-16, the "Spectrum 2" measurement is currently active (indicated by the
"channel active" icon in the tab label).
3. Stop the Sequencer by tapping the "Sequencer" softkey again.
4.4 Operating the instrument
This chapter provides an overview on how to work with the R&S ZNL/ZNLE.
Remote control
In addition to working with the R&S ZNL/ZNLE interactively, located directly at the
instrument, it is also possible to operate and control it from a remote PC. Various meth-
ods for remote control are supported:
●
Connecting the instrument to a (LAN) network
●
Using the web browser interface in a LAN network
●
Using the Windows Remote Desktop application in a LAN network
●
Connecting a PC via the GPIB interface
How to configure the remote control interfaces is described in the R&S ZNL/ZNLE user
manual.
Operating the instrument
