Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<TraceName> Name of the new trace (i.e. the copy).
Note that trace names must be unique within the active setup.
<ToNewDiag> Boolean
OFF (0)
The new trace is assigned to the diagram area of the copied
trace (default, if omitted).
Corresponds to the "Add Trace" GUI function.
ON (1)
The new trace is assigned to a new diagram area.
Corresponds to the "Add Trace + Diagram" GUI function.
Manual operation: See "Add Trace" on page 347
CALCulate<Ch>:PARameter:DELete <TraceName>
Deletes a trace with a specified trace name and channel.
Suffix:
<Ch>
.
Channel number.
Setting parameters:
<TraceName> Trace name, e.g. 'Trc4'. See "Rules for trace names" in Chap-
ter 10.6.1.2, "Trace Manager dialog", on page 349.
Example:
CALCulate4:PARameter:SDEFine 'Ch4Tr1', 'S11'
Create channel 4 and a trace named Ch4Tr1 to measure the
input reflection coefficient S
11
.
CALCulate4:PAR:CAT?
Query the traces assigned to channel 4. Ch4Tr1 is the only
trace assigned to channel 4, so the response is
'CH4TR1,S11'.
CALCulate4:PARameter:SDEFine 'CH4TR2', 'S21';
SDEFine 'CH4TR3', 'S12'; SDEFine 'CH4TR4',
'S22'
Create three more traces for the remaining 2-port S-parameters.
CALCulate4:PARameter:DELete 'CH4TR1'
Delete the first created trace.
CALCulate4:PARameter:DELete:CALL
Delete the remaining three traces in channel 4.
CALCulate:PARameter:DELete:ALL
Delete all traces, including the default trace Trc1 in channel 1.
Usage:
Setting only
Manual operation: See "Delete Trace" on page 348
VNA command reference
