VNA concepts and features
R&S
®
ZNL/ZNLE
302User Manual 1178.5966.02 ─ 20
ble to define which of the peaks are considered as being due to a fault, and to draw up
and export a list of the detected faults.
A more flexible approach with additional configuration possibilities is available with time
domain option R&S ZNL-K2 (see Chapter 9.7.1, "Time domain analysis", on page 294).
9.7.3 Spectrum analyzer function
Option R&S ZNLxx-B1
If the "Spectrum Analyzer" hardware option R&S ZNLxx-B1 is installed, you can use
the R&S ZNLxx to perform signal and spectrum analysis measurements. See the data
sheet and the "Spectrum Analysis" user manual for further information.
●
The "Spectrum Analyzer" hardware option is not available for the R&S ZNLE and
for R&S ZNL14 and R&S ZNL20 with serial numbers below 101200.
For all other R&S ZNL, it can be retrofitted at Rohde&Schwarz service.
●
Option R&S ZNL20-B1 supports frequencies up to 26.5 GHz.
●
The following additional options are only available if the R&S ZNL is equipped with
the spectrum analysis option:
– R&S FPL1-B11 "YIG preselector bypass" (R&S ZNL14|20 only)
– R&S FPL1-B40 "40 MHz Analysis Bandwidth" (keycode option; applies to spec-
trum measurements only)
– R&S FPL1-K7 "Analog Demodulation AM/FM/PM" (software license)
– R&S FPL1-K9 "Measurements with R&S NRP power sensors" (software
license)
– R&S FPL1-K30 "Noise Figure Measurements" (software license)
●
The following R&S FPL1 options can also be used without the spectrum analysis
option:
– R&S FPL1-B4 OCXO frequency reference
– R&S FPL1-B5 Additional interfaces
– R&S FPL1-B10 GPIB interface
– R&S FPL1-B30 DC power supply 12/24 V
– R&S FPL1-B31 Internal Li-ion batteries
Optional extensions and accessories
