Remote command:
DISPlay:LAYout
Diagrams / Rows / Columns
Selects the number of "Diagrams" (or "Rows" and "Columns") to which the traces in the
active channel setup are split. The split is performed according to the selected Split
Type.
If the entered number of "Diagrams" exceeds the number of previously existing traces,
some of the new diagrams are created with default traces.
For a "Split Type" other than "Rows + Cols", only the total number of "Diagrams" can
be specified.
Remote command:
DISPlay:LAYout:GRID
Additional Functionality: SCPI Commands
The analyzer provides remote control commands for efficient diagram handling. The
commands listed below extend the functionality of the "Display > Diagram" and "Dis-
play > Split" softtool panels. For programming examples, refer to "Creating diagrams"
on page 1066.
Remote command:
DISPlay:LAYout:APPLy
DISPlay:LAYout:DEFine
DISPlay:LAYout:EXECute
DISPlay:LAYout:JOIN
10.9.3 Config tab
Displays or hides controls and information elements of the screen and controls the
appearance of the individual diagrams.
Hiding the controls and information elements leaves more space for the diagrams. All
elements can be shown or hidden simultaneously.
Related information
Refer to Chapter 9.2.1, "Display elements of a VNA diagram", on page 194.
Display Lines softtool
