Command reference
R&S
®
ZNL/ZNLE
815User Manual 1178.5966.02 ─ 20
Manual operation: See "Content Selection" on page 430
DISPlay:IWINdow:MARKer<Mk>[:STATe] <TraceName>, <Boolean>
Defines the markers to be displayed in the Info Window.
Suffix:
<Mk>
.
Marker number.
Parameters:
<Boolean> 0 – Marker <Mk> of trace <TraceName> is displayed
1 – Marker <Mk> of trace <TraceName> is hidden
Setting parameters:
<TraceName> Name of the related trace.
Manual operation: See "Content Selection" on page 430
DISPlay:IWINdow[:STATe] <Boolean>
Shows/hides the Info Window
Parameters:
<Boolean> 0 – hide the "Info Window" (default)
1 – show the "Info Window"
Manual operation: See "Info Window" on page 429
DISPlay:LAYout <LayoutMode>
Arranges the diagrams in the screen, leaving the diagram contents unchanged.
Parameters:
<LayoutMode> LINeup | STACk | HORizontal | VERTical | GRID
LINeup the diagrams are arranged side by side.
STACk the diagrams are arranged one on top of the other.
HORizontal the diagrams are arranged in horizontal rows.
VERTical the diagrams are arranged in vertical rows.
GRID the diagrams are arranged as a rectangular matrix. The
number of rows and columns is as defined with command
DISPlay:LAYout:GRID.
Example: See DISPlay:LAYout:GRID
Manual operation: See "Split Type" on page 426
DISPlay:LAYout:APPLy <LayoutId>
Selects a previously defined layout for display in the analyzer screen.
