Remote command:
MMEMory:LOAD:VNETworks<Ch>:DIFFerential:EMBedding<LogPt>
10.14.2 Offset tab
Defines length offset parameters for each port.
Use the complementary dock widget to activate or deactivate length/loss compensation
for selected ports (see Chapter 10.14.1.2, "Offset panel", on page 533).
The marker function Zero Delay at Marker function overwrites the offset parameters.
Background information
Refer to the following sections.
●
Chapter 9.6, "Offset parameters and de-/embedding", on page 277
●
Chapter 9.6.1.1, "Definition of offset parameters", on page 278
●
Chapter 9.6.1.3, "Auto Length", on page 279
●
Chapter 9.6.1.6, "Application and effect of offset parameters", on page 282
●
Chapter 9.6.1.7, "Offset parameters for balanced ports", on page 283
●
Chapter 9.6.1.5, "Fixture Compensation", on page 281
10.14.2.1 Controls on the Offset tab
Offset Embed softtool
