R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
859User Manual 1178.5966.02 ─ 20
Example:
*RST; SOUR:LPOR1 1,2; LPOR2 3,4
Define a balanced port configuration.
CALC:TRAN:VNET:BAL:DEEM:TND STSL
Select the "Serial .s2p data, shunt L" circuit model.
MMEM:LOAD:VNET:BAL:DEEM2 'C:\Users\Public
\Documents\Rohde-Schwarz\ZNL\VNET\Test.s2p',
PMA
Load a Touchstone file and assign it to logical port no. 2.
Manual operation: See "File Name <i>/Inc. Seq. <i>/Swap Gates <i>" on page 539
MMEMory:LOAD:VNETworks<Ch>:DIFFerential:EMBedding<LogPt>
<TouchstoneFile>[, <Interchange>]
Loads data of a Differential match embedding network from the specified Touchstone
*.s2p file.
Use CALCulate<Ch>:TRANsform:VNETworks:BALanced:EMBedding<LogPt>:
PARameters:DATA<Port> to load circuit data from the remote client instead.
The query returns the name of the loaded file.
Suffix:
<Ch>
.
Channel number
<LogPt> Logical port number of a balanced port
Parameters:
<TouchstoneFile> String parameter to specify the name and directory of the loaded
*.s2p file.
If no path is specified the analyzer searches the current direc-
tory, which can be set and queried using MMEMory:
CDIRectory?
<Interchange> FPORts | IPORts | SGATes
FPORts (or omitted)
Standard port sequence (network port 1 towards VNA, network
port 2 towards DUT)
IPORts | SGATes
Inverted port sequence (network port 2 towards VNA, network
port 1 towards DUT)
Example:
MMEM:LOAD:VNET1:DIFF:EMBM1 'C:\Users\Public\
Documents\Rohde-Schwarz\ZNL\Embedding\Test.s2p'
Load a Touchstone file.
Manual operation: See "File Name 1" on page 541
MMEMory:LOAD:VNETworks<Ch>:GLOop:DEEMbedding <TouchstoneFile>
MMEMory:LOAD:VNETworks<Ch>:GLOop:EMBedding <TouchstoneFile>
Loads data from a specified one-port (*.s1p) Touchstone file defining a ground loop
circuit model for de-/embedding.
VNA command reference
