VNA concepts and features

R&S

ZNL/ZNLE

305User Manual 1178.5966.02 ─ 20

●

This option is not available for the R&S ZNLE.

●

The VNA-/Spectrum specific interfaces can only be used in the respective mode

and if the Port Configuration is set accordingly.

●

For the current R&S ZNL14 and R&S ZNL20 models (order nos.1323.0012.14 and

1323.0012.20), the spectrum analysis option is not available and hence the

"Spectrum Mode" functions cannot be used at all.

9.7.10 GPIB interface

Option R&S FPL1-B10

This user-retrofitable plugin-unit provides a GPIB bus connector according to standard

IEEE 488 / IEC 625. The GPIB bus interface is primarily intended for remote control of

the R&S ZNL/ZNLE from a controller. For details, refer to Chapter 14.2.2, "GPIB inter-

face", on page 1112.

9.7.11 Broadband limiter

R&S ZN-B13

If not properly discharged, even a passive DUT can build thousands of volts of static

electricity between its armor and inner conductor. If you are working in an environment

where electrostatic discharges are possible, or if you are not discharging your DUT

before measuring it, make sure that the instrument is properly grounded. You can use

any screw on the VNA chassis to connect it to the ground.

For additional protection, Rohde & Schwarz recommends using broadband limiters

R&S ZN‑B13 (stock number 1303.7840.02) at each port of your R&S ZNL/ZNLE3|4|6.

9.7.12 DC power supply 12/24 V

R&S FPL1-B30

A R&S ZNL that is equipped with this user-retrofitable plugin-unit can be connected to

DC power supplies from +12 V to +24 V and from 13 A to 6.5 A.

This option is not available for the R&S ZNLE.

Optional extensions and accessories
