R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
750User Manual 1178.5966.02 ─ 20
Parameter Circuit model Pictogram
LSG Serial L, shunt C
GSG Serial C, shunt C
SGL Shunt C, serial L
SLG Shunt L, serial C
SGG Shunt C, serial C
Table 11-10: Circuit models for balanced port (and port pair) de-/embedding
Parameter Circuit model Pictogram
FIMPort File import, generic 4-port (.s4p, no circuit model)
STSL Serial Touchstone (.s2p) data, shunt L
STSC Serial Touchstone (.s2p) data, shunt C
VNA command reference
