Operating modes, applications, channel setups, and result displays
R&S
®
ZNL/ZNLE
93User Manual 1178.5966.02 ─ 20
1. Configure a channel setup for each measurement configuration as required, includ-
ing the sweep mode.
2. In the toolbar, select the "Sequencer" icon.
The "Sequencer" menu is displayed.
3. Toggle the "Sequencer" softkey to "On".
A continuous sequence is started immediately.
4. To change the Sequencer mode and start a new sequence immediately, select the
corresponding mode softkey, or press the [Run Single] or [Run Cont] key.
The measurements configured in the currently active channel setups are per-
formed one after the other in the order of the tabs until the Sequencer is stopped.
The result displays in the individual channel setups are updated as the measure-
ments are performed.
To stop the sequencer
► To stop the Sequencer temporarily, press the highlighted [Run Single] or [Run
Cont] key (not for a channel-defined sequence). To continue the Sequencer, press
the key again.
To stop the Sequencer permanently, select the "Sequencer" icon in the toolbar and
toggle the "Sequencer" softkey to "Off".
Mixed VNA operation
If the sequencer is running and both a VNA and other channel setups are active, then
changing a parameter can cause the measurements to halt. If this happens, turn the
sequencer "Off" and then "On" again.
Running a sequence of measurements
