Rockwell Automation PowerFlex 7000

2-216 Parameters Listed by Group
7000-TD002A-EN-P – September 2007
PWM Parameters
Name Min. Max. Default Units
Read-
Only
Access
95 Rec Pulse Number 0 36 - Y Service
295 Inv Pulse Number 0 65535 - Y Service
378 Inv PWM Pattern - - - Y Service
756 Idc 3 Pulse 0.000 10.000 - pu Y Service
757 Idc 5 Pulse 0.000 10.000 - pu Y Service
379 Vdc Ref 5p to 3p 0.00 1.50 0.10 pu N Service
465 Vdc Ref 7p to 5p 0.00 1.50 0.50 pu N Service
560 Idc Fac 3p to 5p 0.00 2.00 1.00 N Service
640 Idc Fac 7p to 5p 0.00 2.00 1.00 N Service
155 Rec PWM Max Freq 100 1000 440 Hz N Service
154 Inv PWM Max Freq 100 1000 440 Hz N Service
620 Rec DvcGat SeqnA 0 65535 - Y Service
621 Rec DvcGat SeqnB 0 65535 - Y Service
626 Rec DvcGat SeqnC 0 65535 - Y Service
627 Rec DvcDiag FbkA 0 65535 - Y Service
628 Rec DvcDiag FbkB 0 65535 - Y Service
629 Rec DvcDiag FbkC 0 65535 - Y Service
584 Inv DvcGat Seqn 0 65535 - Y Service
608 Inv DvcDiag FbkA 0 65535 - Y Service
609 Inv DvcDiag FbkB 0 65535 - Y Service
618 Inv DvcDiag FbkC 0 65535 - Y Service
311 PFC Mod Index 0.00 1.50 - Y Service
Liquid Cooling Parameters
Name Min. Max. Default Units
Read-
Only
Access
380 Coolant Temp C 0 65535 - C Y Service
381 Coolant Temp F 0 65535 - F Y Service
477 Fan Config - - 3 In-line N Service
478 Coolant Temp Wrn 35 85 49 C N Service
483 Coolant Temp Trp 35 85 54 C N Service
432 Pump Duty Cycle 1 720 8 hrs N Service
449 Fan Duty Cycle 1 720 8 hrs N Service
Security Parameters
Name Min. Max. Default Units
Read-
Only
Access
708 Port Mask Act - - - Hex Y Advanced
709 Port Logic Mask - - 0000000001111111 Hex N Advanced
710 Logic Mask Act - - - Hex Y Advanced
711 Write Mask Cfg - - 0000000001111111 Hex N Advanced
712 Write Mask Act - - - Hex Y Advanced
